AO Extension

The Loxone AO Extension provides 4 analog 0-10V outputs. Perfect for transmitting analog control signals in the 0-10V range. This can be used to control heaters, electronic ballasts, pumps and much more.

Features:

• Instantaneous output: max. 20mA
• Continuous output: max. 10mA
• Resolution: 0.1V

Technical details:

Supply voltage:
14 … 28 VDC

Product dimensions:
88 x 35.4 x 57 mm / 3.46 x 1.39 x 2.24” (L x W x H), 2 division units

Please note that this is a control signal. The analog output may only be loaded with a maximum of 20mA.
